W6231D

Description
This product is a dual-channel open collector output type photocoupler composed of two infrared light-emitting diodes and two photosensitive processing chips, packaged in DIP8 ceramic tube shell. The operating temperature is -55℃～+100℃, meeting the application requirements of high reliability and environmental adaptability.

Application                                                                                                      Features

A/D, D/A conversion digital isolation                                                            Isolation voltage: ＞1000V
Computer interface circuit                                                                               Power supply voltage: 2.7V~5.5V
Microsystem interface circuit                                                                          Maximum speed: 10Mbit/s
High-speed logic circuit                                                                                    LSTTL/TTL compatible
Level conversion                                                                                                  Operating temperature: -55℃~+100℃
Instrument input and output isolation
Ground loop elimination
Pulse transformer replacement

Dimensions: 11.70mm*7.62mm*3.50mm                                         Packaging: DIP8
